- Код товару: 1SDA054737R1
- Артикул: 1SDA054737R1
- Наявність: Pre-Order
9 343.68грн.
Знайшли дешевше?
Основні характеристики
Всі характеристики
Кількість полюсів::
3
Номінальна робоча напруга::
690 V AC; 750 V DC
Тип клемного з'єднання::
Передний удлиненный вывод; Выключатели втычного исполнения
1 Depth / Length::
306 мм
1 EAN::
8015644558512
T4 P FP 3p EF ПІДПРИЄМСТВО ФІКСОВАНОЇ ЧАСТИНИ ДЛЯ C.BREAKER TMAX ТРИЙ ПОЛЬ З РОЗШИРЕНИМИ ПЕРЕДНІМИ ТЕРМІНАЛИ T4
Характеристики
Характеристики
Кількість полюсів:
3
Номінальна робоча напруга:
690 V AC; 750 V DC
Тип клемного з'єднання:
Передний удлиненный вывод; Выключатели втычного исполнения
1 Depth / Length:
306 мм
1 EAN:
8015644558512
1 Gross Weight:
1.2 kg
1 Height:
72 мм
1 Units:
1 штука
1 Width:
72 мм
WEEE Category:
5. Small Equipment (No External Dimension More Than 50 cm)
Європейський товарний код (EAN):
8015644558512
Інструкції та керівництва (частина 2):
ITSCE-RH0100001
Інструкції та керівництва:
1SDH000436R0811
версія:
P
Випробувальна напруга при промисловій частоті протягом 1 хвилини:
not applicable V
Код класифікації об'єкта:
Q
Назва виробу:
Accessory
Номер митного тарифу:
85389099
Основний тип вироби:
SACE Tmax T
Підтип:
T4
Підходить для класу виробів:
Moulded Case Circuit Breakers
Підходить для:
T4
Пристрій:
Fixed Part
Тип виробу:
FP
Чиста вага виробу:
kg; 1
Чистий висота вироби:
209 мм
Чистий товщина вироби:
50 мм
Чистий ширина вироби:
105 мм
Технічна інформація
