- Код товару: 1SDA054762R1
- Артикул: 1SDA054762R1
- Наявність: Pre-Order
19 965.60грн.
Знайшли дешевше?
Основні характеристики
Всі характеристики
Кількість полюсів::
3
Номінальна робоча напруга::
690 V AC; 750 V DC
Номінальний безперервний струм (I u )::
630 A
Тип клемного з'єднання::
Передний удлиненный вывод; Выключатели втычного исполнения
1 Depth / Length::
359 мм
T5 630 P FP 3p EF ПІДПРИЄМСТВО ФІКСОВАНОЇ ЧАСТИНИ ДЛЯ C.BREAKER TMAX ТРИПЛІТНИЙ З РОЗШИРЕНИМИ ПРЕДНІМИ ТЕРМІНАЛИ T5 630
Характеристики
Характеристики
Кількість полюсів:
3
Номінальна робоча напруга:
690 V AC; 750 V DC
Номінальний безперервний струм (I u ):
630 A
Тип клемного з'єднання:
Передний удлиненный вывод; Выключатели втычного исполнения
1 Depth / Length:
359 мм
1 EAN:
8015644558918
1 Gross Weight:
4 kg
1 Height:
183 мм
1 Units:
1 штука
1 Width:
183 мм
WEEE Category:
5. Small Equipment (No External Dimension More Than 50 cm)
Європейський товарний код (EAN):
8015644558918
Інструкції та керівництва:
1SDC210015D0201
версія:
P
Код класифікації об'єкта:
Q
Назва виробу:
Accessory
Номер митного тарифу:
85389099
Основний тип вироби:
SACE Tmax T
Підтип:
T5
Підходить для класу виробів:
Moulded Case Circuit Breakers
Підходить для:
T5
Тип виробу:
FP
Чиста вага виробу:
kg; 1.5
Чистий висота вироби:
273 мм
Чистий товщина вироби:
50 мм
Чистий ширина вироби:
