- Код товару: 1SDA062050R1
- Артикул: 1SDA062050R1
- Наявність: Pre-Order
0.00грн.
Знайшли дешевше?
Основні характеристики
Всі характеристики
Кількість полюсів::
4
Номінальна робоча напруга::
690 V AC
Номінальний безперервний струм (I u )::
1600 A
Тип клемного з'єднання::
Задние плоские горизонтальные выводы; Передний удлиненный вывод; Выключатели выкатного исполнения
1 EAN::
8015644609139
T7-X1 W FP 4p HR-EF ЗАМЕЧАЛЬНА ЧАСТИНА, Знята на C.BREAKER ЧЕТВЕРТИЙ ПОЛЬ ТМАКС-ЕМАКС З ВЕЛИКИМИ ЗАДНІМИ ХОРІЗОНТАЛЬНИМИ ТЕРМІНАЛАМИ І НИЖИМИ РОЗШИРЕНИМИ ПЕРЕДНІМИ терміналами T7-X1
Характеристики
Характеристики
Кількість полюсів:
4
Номінальна робоча напруга:
690 V AC
Номінальний безперервний струм (I u ):
1600 A
Тип клемного з'єднання:
Задние плоские горизонтальные выводы; Передний удлиненный вывод; Выключатели выкатного исполнения
1 EAN:
8015644609139
1 Gross Weight:
26.1 kg
1 Units:
1 штука
WEEE Category:
5. Small Equipment (No External Dimension More Than 50 cm)
Європейський товарний код (EAN):
8015644645946
Інструкції та керівництва:
1SDH000460R4269
версія:
W
Код класифікації об'єкта:
Q
Назва виробу:
Accessory
Номер митного тарифу:
85389099
Основний тип вироби:
SACE Tmax T
Підтип:
T7-X1
Тип виробу:
FP
Чиста вага виробу:
kg; 24.6
Чистий висота вироби:
343 мм
Чистий товщина вироби:
251 мм
Чистий ширина вироби:
348 мм
